- YA Series Vibrating Screen
-
YA Series Vibrating Screen
Capacity:22-1300t/h
Feed size:0-400mm
Application:Product classification in mining, building materials, transportation, energy, chemical industry and other industries
Overview
YA Series Vibrating Screen is of multiple layers and vibrating circularly. It is of long screen line, correct to screen in all kinds of specification products. Our Vibrating Screen adopts the barrel type of eccentric shaft vibration exciter and eccentric block to adjust the swing. It is also of reliable structure, strong exciting force, high screening efficiency, low vibrating noise, long durability, convenient maintenance, safe operation, etc. our Vibrating Screen is widely used for screening in mines, building material, transportation, energy sources, chemical industry, etc.
Features
Rubber Isolation Spring
Longer service life, little noise, stable resonance region.
Motor
High quality motor makes sure stable working of machine.
Eccentric Shaft Vibration Exciter
Main machine is under protection, easy to be replaced, and maintenance costs is reduced.
High Quality Screen
Longer service life, hard to plug hole.
Specifications - Technical Data
|
Model |
Layer of Screen |
Size of Sieve Pore (mm) |
|
Capacity (m³/h) |
Motor Power (kW) |
|
2YA1548 |
2 |
3~100 |
300 |
22~160 |
15 |
|
3YA1548 |
3 |
3~100 |
300 |
22~160 |
15 |
|
4YA1548 |
4 |
3~100 |
300 |
22~160 |
15 |
|
2YA1848 |
2 |
3~100 |
300 |
32~276 |
18.5 |
|
3YA1848 |
3 |
3~100 |
300 |
32~276 |
18.5 |
|
4YA1848 |
4 |
3~100 |
300 |
32~276 |
18.5 |
|
2YA1860 |
2 |
3~100 |
300 |
65~586 |
22 |
|
3YA1860 |
3 |
3~100 |
300 |
65~586 |
22 |
|
4YA1860 |
4 |
3~100 |
300 |
65~586 |
22 |
|
2YA2160 |
2 |
3~100 |
300 |
81~720 |
30 |
|
3YA2160 |
3 |
3~100 |
300 |
81~720 |
30 |
|
4YA2160 |
4 |
3~100 |
300 |
81~720 |
37 |
|
2YA2460 |
2 |
3~150 |
300 |
90~810 |
37 |
|
3YA2460 |
3 |
3~150 |
300 |
90~810 |
37 |
|
4YA2460 |
4 |
3~150 |
300 |
90~810 |
37 |
|
2YK3072 |
2 |
3~200 |
300 |
180~1300 |
30×2 |
|
3YK3072 |
3 |
3~200 |
300 |
180~1300 |
30×2 |
